在 Mac 上用 Vagrant 安装 K8s

本指南将帮助你在macOS上使用Kubespray、Vagrant和Parallels Desktop搭建一个完整的Kubernetes测试集群。

📋 1. 环境准备

1.1 系统要求

• macOS（Apple Silicon或Intel）
• 至少16GB内存
• 50GB以上可用磁盘空间

1.2 软件清单

• Parallels Desktop（商业版）
• Homebrew
• Vagrant + vagrant-parallels插件
• Python 3.12+ 及虚拟环境
• Git

🚀 2. 安装步骤

2.1 安装Parallels Desktop

💡 提示： 需要购买商业版许可证，可考虑在闲鱼等平台购买

安装完成后确保Parallels Desktop正常运行。

2.2 配置网络代理（可选）

如果你的网络环境需要代理，创建代理配置脚本：

vim ~/.zshrc

添加以下内容：

# 网络代理配置
proxy_url="http://172.0.0.1:7890"  # 修改为你的代理地址
export no_proxy="10.0.0.0/8,192.168.16.0/20,localhost,127.0.0.0/8,registry.ocp.local,.svc,.svc.cluster-27,.coding.net,.tencentyun.com,.myqcloud.com"# 代理控制函数
enable_proxy() {export http_proxy="${proxy_url}"export https_proxy="${proxy_url}"git config --global http.proxy "${proxy_url}"git config --global https.proxy "${proxy_url}"echo "✅ 代理已启用: ${proxy_url}"
}disable_proxy() {unset http_proxyunset https_proxygit config --global --unset http.proxygit config --global --unset https.proxyecho "❌ 代理已禁用"
}# 默认禁用代理
disable_proxy

应用配置：

source ~/.zshrc# 如需启用代理
enable_proxy

2.3 安装Homebrew

/bin/bash -c "$(curl -fsSL https://raw.githubusercontent.com/Homebrew/install/HEAD/install.sh)"# 更新Homebrew
brew update

2,4 准备项目目录

# 创建项目目录
mkdir -p ~/Projects/k8s-testing
cd ~/Projects/k8s-testing# 克隆Kubespray项目
git clone https://github.com/upmio/kubespray-upm.git
cd kubespray-upm

2.5 安装Vagrant及插件

# 安装Vagrant
brew tap hashicorp/tap
brew install hashicorp/tap/hashicorp-vagrant# 验证安装
vagrant --version# 安装Parallels插件
vagrant plugin install vagrant-parallels# 查看已安装插件
vagrant plugin list

2.6 配置Python环境

2.6.1 安装Python管理工具

brew install  python

2.6.2 配置Shell环境

vim ~/.zshrc

添加以下配置：

# Python环境配置
alias python=python3
alias pip=pip3

应用配置：

source ~/.zshrc

2.6.3 验证Python环境

python --version
pip --version

2.6.4 安装 pyenv

安装依赖

brew install openssl readline sqlite3 xz zlib

安装pyenv

curl https://pyenv.run | bash

vim ~/.zshrc

添加以下配置：

export PYENV_ROOT="$HOME/.pyenv"
export PATH="$PYENV_ROOT/bin:$PATH"
eval "$(pyenv init -)"

应用配置：

source ~/.zshrc

2.6.5 升级Python工具

python -m pip install --upgrade pip
pyenv update

2.6.6 创建Python虚拟环境

# 安装Python 3.12.11
pyenv install 3.12.11# 创建专用虚拟环境
pyenv virtualenv 3.12.11 kubespray-3.12.11-env#为项目设置默认 Python 环境
pyenv local kubespray-3.12.11-env# 安装项目依赖
pip install -r requirements.txt

2.7 配置Kubespray

2.7.1 配置核心配置文件

# 复制Vagrant配置文件
cp vagrant_setup_scripts/Vagrantfile ./Vagrantfile# 创建vagrant配置目录
mkdir -p vagrant

2.7.1.1 配置集群config.rb

$ vim  vagrant/config.rb
# Vagrant configuration file for Kubespray
# Vagrant configuration file for Kubespray
# Kubespray Vagrant Configuration Sample
# This file allows you to customize various settings for your Vagrant environment
# Copy this file to vagrant/config.rb and modify the values according to your needs# =============================================================================
# PROXY CONFIGURATION
# =============================================================================
# Configure proxy settings for the cluster if you're behind a corporate firewall
# Leave empty or comment out if no proxy is needed# HTTP proxy URL - used for HTTP traffic
# Example: "http://proxy.company.com:8080"
# $http_proxy = ""
$http_proxy = "http://10.211.55.2:7890"# HTTPS proxy URL - used for HTTPS traffic
# Example: "https://proxy.company.com:8080"
# $https_proxy = ""
$https_proxy = "http://10.211.55.2:7890"# No proxy list - comma-separated list of hosts/domains that should bypass proxy
# Common entries: localhost, 127.0.0.1, local domains, cluster subnets
# Example: "localhost,127.0.0.1,.local,.company.com,10.0.0.0/8,192.168.0.0/16"
# $no_proxy = ""
$no_proxy = "localhost,127.0.0.1,192.168.0.0/16,10.0.0.0/8,172.16.0.0/12,::1,.demo.com"# Additional no proxy entries - will be added to the default no_proxy list
# Use this to add extra domains without overriding the defaults
# Example: ".internal,.corp,.k8s.local"
# $additional_no_proxy = ""
$additional_no_proxy = "localhost,127.0.0.1,192.168.0.0/16,10.0.0.0/8,172.16.0.0/12,::1,.demo.com"# =============================================================================
# ANSIBLE CONFIGURATION
# =============================================================================
# Ansible verbosity level for debugging (uncomment to enable)
# Options: "v" (verbose), "vv" (more verbose), "vvv" (debug), "vvvv" (connection debug)
#$ansible_verbosity = "vvv"# =============================================================================
# VIRTUAL MACHINE CONFIGURATION
# =============================================================================
# Prefix for VM instance names (will be followed by node number)
$instance_name_prefix = "k8s"# Default CPU and memory settings for worker nodes
$vm_cpus = 8                    # Number of CPU cores per worker node
$vm_memory = 16384              # Memory in MB per worker node (16GB)# Master/Control plane node resources
$kube_master_vm_cpus = 4        # CPU cores for Kubernetes master nodes
$kube_master_vm_memory = 4096   # Memory in MB for Kubernetes master nodes (4GB)# UPM Control plane node resources (if using UPM)
$upm_control_plane_vm_cpus = 12      # CPU cores for UPM control plane
$upm_control_plane_vm_memory = 24576 # Memory in MB for UPM control plane (24GB)# =============================================================================
# STORAGE CONFIGURATION
# =============================================================================
# Enable additional disks for worker nodes (useful for storage testing)
$kube_node_instances_with_disks = true# Size of additional disks in GB (200GB in this example)
$kube_node_instances_with_disks_size = "200G"# Number of additional disks per node
$kube_node_instances_with_disks_number = 1# Directory to store additional disk files
$kube_node_instances_with_disk_dir = ENV['HOME'] + "/kubespray_vm_disk/upm_disks"# Suffix for disk file names
$kube_node_instances_with_disk_suffix = "upm"# VolumeGroup configuration for additional disks
# Name of the VolumeGroup to create for additional disks
$kube_node_instances_volume_group = "local_vg_dev"# Enable automatic VolumeGroup creation for additional disks
$kube_node_instances_create_vg = true# =============================================================================
# CLUSTER TOPOLOGY
# =============================================================================
# Total number of nodes in the cluster (masters + workers)
$num_instances = 5# Number of etcd instances (should be odd number: 1, 3, 5, etc.)
$etcd_instances = 1# Number of Kubernetes master/control plane instances
$kube_master_instances = 1# Number of UPM control instances (if using UPM)
$upm_ctl_instances = 1# =============================================================================
# SYSTEM CONFIGURATION
# =============================================================================
# Vagrant Provider Configuration
# Specify the Vagrant provider to use for virtual machines
# If not set, Vagrant will auto-detect available providers in this order:
# 1. Command line --provider argument (highest priority)
# 2. VAGRANT_DEFAULT_PROVIDER environment variable
# 3. Auto-detection of installed providers (parallels > virtualbox > libvirt)
#
# Supported options: "virtualbox", "libvirt", "parallels"
#
# Provider recommendations:
# - virtualbox: Best for development and testing (free, cross-platform)
# - libvirt: Good for Linux production environments (KVM-based)
# - parallels: Good for macOS users with Parallels Desktop
#
# Leave commented for auto-detection, or uncomment and set to force a specific provider
# $provider = "virtualbox"# Timezone for all VMs
$time_zone = "Asia/Shanghai"# Ntp Sever Configuration
$ntp_enabled = "True"
$ntp_manage_config = "True"# Operating system for VMs
# Supported options: "ubuntu2004", "ubuntu2204", "centos7", "centos8", "rockylinux8", "rockylinux9", etc.
$os = "rockylinux9"# =============================================================================
# NETWORK CONFIGURATION
# =============================================================================
# Network type: "nat" or "bridge"
#
# nat: Auto-detect provider network and assign IPs (recommended)
#   - Automatically detects provider default network (usually 192.168.x.0/24)
#   - Uses NAT networking for VM internet access
#   - VMs can communicate with each other and host
#   - Simpler setup, no bridge configuration required
#   - Recommended for development and testing
#
# bridge: Use bridge network with manual IP configuration
#   - Requires manual bridge interface setup on host
#   - VMs get IPs from same subnet as host network
#   - Direct network access, VMs appear as separate devices on network
#   - More complex setup, requires bridge configuration
#   - Recommended for production-like environments
$vm_network = "nat"# Starting IP for the 4th octet (VMs will get IPs starting from this number)
# Used in both nat (with auto-detected subnet) and bridge modes
$subnet_split4 = 100# The following network settings are only used when $vm_network = "bridge"
# For nat, subnet/gateway/netmask are auto-detected from provider# Network subnet (first 3 octets) - bridge only
# $subnet = "10.37.129"# Network configuration - bridge only
# $netmask = "255.255.255.0"      # Subnet mask
# $gateway = "10.37.129.1"        # Default gateway
# $dns_server = "8.8.8.8"         # DNS server
$dns_server = "10.211.55.2"  # （可选）如果配置私有dns，需要在macOS 安装 dns server，否则重启虚拟机，可能会有pod异常。
# Bridge network interface (required when using "bridge")
# Example: On linux, libvirt bridge interface name: br0
# $bridge_nic = "br0"
# Example: On linux, vitrulbox bridge interface name: virbr0
# $bridge_nic = "virbr0"# =============================================================================
# KUBERNETES CONFIGURATION
# =============================================================================
# Container Network Interface (CNI) plugin
# Options: "calico", "flannel", "weave", "cilium", "kube-ovn", etc.
$network_plugin = "calico"# Cert-Manager Configuration
$cert_manager_enabled = "True"             # Enable cert-manager# Local Path Provisioner Configuration
$local_path_provisioner_enabled = "False"    # Enable local path provisioner
$local_path_provisioner_claim_root = "/opt/local-path-provisioner/"  # Local path root# Ansible inventory directory
$inventory = "inventory/sample"# Shared folders between host and VMs (empty by default)
$shared_folders = {}# Kubernetes version to install
$kube_version = "1.33.3"
# Kubespray Vagrant Configuration Sample

2.7.1.2 配置 containerd.yml（可选）

$ vim inventory/sample/group_vars/all/containerd.yml
---
# Please see roles/container-engine/containerd/defaults/main.yml for more configuration options# containerd_storage_dir: "/var/lib/containerd"
# containerd_state_dir: "/run/containerd"
# containerd_oom_score: 0# containerd_default_runtime: "runc"
# containerd_snapshotter: "native"# containerd_runc_runtime:
#   name: runc
#   type: "io.containerd.runc.v2"
#   engine: ""
#   root: ""# containerd_additional_runtimes:
# Example for Kata Containers as additional runtime:
#   - name: kata
#     type: "io.containerd.kata.v2"
#     engine: ""
#     root: ""# containerd_grpc_max_recv_message_size: 16777216
# containerd_grpc_max_send_message_size: 16777216# Containerd debug socket location: unix or tcp format
# containerd_debug_address: ""# Containerd log level
# containerd_debug_level: "info"# Containerd logs format, supported values: text, json
# containerd_debug_format: ""# Containerd debug socket UID
# containerd_debug_uid: 0# Containerd debug socket GID
# containerd_debug_gid: 0# containerd_metrics_address: ""# containerd_metrics_grpc_histogram: false# Registries defined within containerd.
containerd_registries_mirrors:- prefix: quay.iomirrors:- host: https://quay.nju.edu.cncapabilities: ["pull", "resolve"]skip_verify: false- host: http://harbor.demo.comcapabilities: ["pull", "resolve"]skip_verify: true- prefix: docker.iomirrors:- host: http://harbor.demo.comcapabilities: ["pull", "resolve"]skip_verify: true- host: https://dockerproxy.comcapabilities: ["pull", "resolve"]skip_verify: false- prefix: ghcr.iomirrors:- host: https://ghcr.nju.edu.cncapabilities: ["pull", "resolve"]skip_verify: false- host: https://ghcr.dockerproxy.comcapabilities: ["pull", "resolve"]skip_verify: false- prefix: registry.k8s.iomirrors:- host: https://k8s.mirror.nju.edu.cncapabilities: ["pull", "resolve"]skip_verify: false- host: https://k8s.dockerproxy.comcapabilities: ["pull", "resolve"]skip_verify: false# containerd_max_container_log_line_size: -1

🔧 3. 部署集群

3.1 启动虚拟机并部署K8s

⚠️ 注意： 此过程需要10-15分钟，具体时间取决于网络状况和硬件性能

vagrant up --no-parallel

3.2 如果部署失败，可以重试

vagrant provision --provision-with ansible

🎯 4. 配置kubectl访问

4.1 安装kubectl客户端

# 下载kubectl（Apple Silicon版本）
curl -LO "https://dl.k8s.io/release/$(curl -L -s https://dl.k8s.io/release/stable.txt)/bin/darwin/arm64/kubectl"# 设置执行权限并移动到PATH目录
chmod +x kubectl && mv kubectl /usr/local/bin/kubectl# 验证安装
kubectl version --client

4.2 配置集群访问

# 复制kubeconfig文件
mkdir -p ~/.kube
cp inventory/sample/artifacts/admin.conf ~/.kube/config# 验证集群连接
kubectl get nodes
kubectl get pods --all-namespaces

📦 5. 安装Helm（可选）

# 下载安装脚本
curl -fsSL -o get_helm.sh https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3# 执行安装
chmod 700 get_helm.sh
./get_helm.sh# 验证安装
helm version

🧹 6. 清理环境

6.1 销毁虚拟机

vagrant destroy -f

6.2 退出Python虚拟环境

pyenv deactivate

🛠️ 7. 故障排除

7.1 常见问题

1. Vagrant启动失败

• 检查Parallels Desktop是否正常运行
• 确认系统资源充足（内存、磁盘空间）
• 检查网络连接状态

2. Python依赖安装失败

• 确认已激活正确的虚拟环境
• 尝试升级pip：pip install --upgrade pip
• 检查网络代理设置

3. kubectl无法连接集群

• 确认kubeconfig文件路径正确
• 检查虚拟机网络状态：vagrant status
• 验证SSH连接：vagrant ssh

4. 网络问题

• 如在国内环境，建议配置代理
• 可以尝试使用国内镜像源

7.2 有用的调试命令

# 检查Vagrant状态
vagrant status# 查看虚拟机日志
vagrant ssh -c "sudo journalctl -u kubelet"# 重新加载Vagrant配置
vagrant reload# 查看集群状态
kubectl cluster-info
kubectl get componentstatuses

📝 8. 总结

通过以上步骤，你应该已经成功搭建了一个基于Kubespray的Kubernetes测试集群。这个环境非常适合：

• 学习Kubernetes核心概念
• 测试应用部署
• 验证集群配置
• 开发云原生应用

💡 提示： 建议定期备份重要的配置文件和项目代码，避免因误操作导致数据丢失。

---
